A, water heater right end cover and the vertical walls between distance leaving at least 30cm (referenced above) to facilitate future maintenance; the distance between the water heater installation position with a power supply socket location must be less than the length of the power line.
B, hanging water heater walls should be solid, can withstand 4 doubly when the water is full of weight; unless bearing wall or hollow brick wall must take corresponding measures to protect them. Installed with bracket, use through wall screws, backplane;
C, electric water heater installed in the floor drain drainage can not do not place;
D, home to the water power, convenient installation and after water test machine;
E, in the completion of renovation (installed in bathrooms need to wait after drying the tiles to install; non hidden installation requires the ceiling before installing, half hidden or concealed need to install to install the water heater to the ceiling; F), electric water heater power line diameter and a power socket to illustrate: power 1500W (including) the following 1500W to 3000W 5000W 5000W-8000W power line diameter minimum requirements (the machine itself line sizes) is equal to or larger than 1.0mm2 x 3 core is more than or equal to 1.5 mm2 * 3 core is more than or equal to 4.0mm2 x 3 core is more than or equal to 6.0mm2 x 3 core line diameter wire material size material is the best solid core copper wire, and GB line. Socket and air switch socket 10a, no need to separate supporting air switch socket 16a, without the need for a separate supporting air air switch switch is more than or equal to 25A meter capacity is more than or equal to 30A air switch is more than or equal to 37a meter capacity is more than or equal to 40A
Remarks:
1, if your home power outlet and water heater requirements of the standard does not meet the requirements of the machine can not be normal use, you need to change the specifications of the socket replacement;
2, for large power water heaters, such as 3000W above, you must use the air switch control, is prohibited to use the power plug and socket to the machine power supply;
3, air switch is recommended choose has the function of leakage protection, and ratings should choose a most close to the machine working current value, such as the working current of the water heater is 25A, 30A air switch the most suitable, and is not the bigger the better, otherwise it will not protective effect.
Special tip: Haier electric water heater installed only three bolts. Three bolts of the above two is main bearing part, and has been calculation and strict test and injection machine double weight), can guarantee the machine wall safety; installed below a bolt is charged ground early warning system installation, also when the side of the installation position of the lower part of a pipeline can choose another location to avoid pipeline.
